Product Description
This Mercedes Sprinter kit is designed to fit in the lower grille location of the 2014 - 2017 models. This 20 inch kit utilizes our 20 inch S8 LED Light bar in our signature Driving/Combo pattern translating to a smooth blend of distance and near field lighting.
For the enthusiast who demands performance lighting, reliability, and purchase protection courtesy of our lifetime warranty.
Please note that this kit does not include a harness, the applicable harness for this light bar is sku 640115.
Baja Designs Features:
- Satisfactions Guarantee - 30 Day Money Back Guarantee
- Limited Lifetime Warranty - Complete Purchase Protection
- uService - Replaceable Lenses And Optics
- ClearView - All The Light, Right Where You Need It.
- MoistureBlock - Waterproof, Rain Proof, Submersible
- CopperDrive - Only LED Driven At 100 percent
- 5000K Daylight - Less Driver Fatigue, Natural Color
Specifications:
- Lumens: 6,350 Utilizing 8 Cree LEDs
- Wattage/Amps: 60W / 4.00A
- Dimensions: 10 inch x 3 inch x 1.6 inch
- Weight: 2.4 lbs
- LED Life Expectancy: 49,930 Hours
- Front Lens: Hard Coated Polycarbonate
- Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
- Bezel: Billet Machined Aluminum
- Hardware and Bracket Material: Stainless Steel
- Exceeds MIL-STD810G (Mil-Spec Testing)
- Built-In Overvoltage Protection
- IP69K (Waterproof up to 9ft and Pressure Washable)
- IK10 Compliant (Mechanical Impact Testing)
(S8 Patent D780,964)
Application:
- 2014 - 2017 Mercedes Sprinter
Includes:
- S8 20 inch LED Light Bar
- U-Cradle Mounting Brackets
Patterns:
Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 Degree) and spot (9 Degree) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)
